HD Metal Band Saw Blade Various Size And Pitch Specifications For Different Material Processing Jobs
Product Introduction
The JSSCD HD Bi-Metal Band Saw Blade is a high-performance metal cutting blade developed for hard and difficult-to-cut materials that require higher tooth hardness, wear resistance and impact resistance.
The HD series uses Japanese-imported M51 special high-speed steel as the tooth material and B318 alloy steel as the backing material. After a specialized heat treatment process, the tooth hardness can reach HRC 69–70, providing high tooth-tip hardness, excellent wear resistance and the ability to withstand stronger impact forces during cutting.
Combined with the ductile backing material, the HD blade provides a balance of tooth hardness and blade toughness. It is particularly suitable for materials that are difficult to cut with conventional M42 bi-metal blades, including special alloy steel, high-temperature alloy steel, tool steel and mold steel.
Key Features
M51 Special High-Speed Steel Teeth
The HD series uses Japanese-imported M51 special high-speed steel for the tooth tips, providing higher hardness and wear resistance than conventional M42 tooth material.
HRC 69–70 Tooth Hardness
After specialized heat treatment, the tooth hardness can reach HRC 69–70, helping the blade withstand demanding cutting conditions.
Excellent Wear Resistance
The high-hardness M51 tooth material is designed for applications where conventional blades may experience faster tooth wear.
High Impact Resistance
The HD tooth structure is designed to withstand stronger impact forces during cutting hard and difficult-to-cut materials.
B318 Alloy Steel Backing
The blade body uses B318 alloy steel as the backing material, providing the toughness required to support the high-hardness cutting edge.
Hardness + Toughness Balance
The combination of a high-hardness M51 tooth tip and a more ductile backing material provides a balance between cutting-edge durability and blade toughness.
Designed for Difficult-to-Cut Materials
HD is suitable for materials that may be difficult for M42 bi-metal blades to handle, including special alloy steel, high-temperature alloy steel, tool steel and mold steel.
Multiple Tooth Pitch Options
The HD series is available in multiple blade sizes and tooth pitches to accommodate different workpiece dimensions and cutting requirements.
Available Sizes & Tooth Pitches
|
Blade Size (Width * Thickness)
|
Available Tooth Pitch / TPI
|
|
19 * 0.90 mm
|
10/14, 8/12, 6/10, 5/8, 4/6, 3/4
|
|
27 * 0.90 mm
|
10/14, 8/12, 6/10, 5/8, 4/6, 3/4, 2/3
|
|
34 * 1.10 mm
|
10/14, 8/12, 6/10, 5/8, 4/6, 3/4, 2/3, 1.4/2
|
|
41 * 1.30 mm
|
5/8, 4/6, 3/4, 2/3, 1.4/2
|
|
54 * 1.60 mm
|
3/4, 2/3, 1.4/2, 1/1.5, 0.75/1.25
|
|
67 * 1.60 mm
|
3/4, 2/3, 1.4/2, 1/1.5, 0.75/1.25
|
|
80 * 1.60 mm
|
3/4, 2/3, 1.4/2, 1/1.5, 0.75/1.25
|
Application
The JSSCD HD Bi-Metal Band Saw Blade is designed for demanding metal cutting applications involving hard, high-strength and difficult-to-cut materials.
Suitable Materials
- Special alloy steel
- High-temperature alloy steel
- Tool steel
- Mold steel
- Hard alloy steel
- Other difficult-to-cut steel materials
The HD series is particularly suitable for applications where conventional M42 bi-metal band saw blades may not provide sufficient cutting performance.
Recommended Applications
- Heavy-duty metal cutting
- Tool steel cutting
- Mold steel cutting
- Alloy steel processing
- High-temperature alloy processing
- Steel service centers
- Machinery manufacturing
- Industrial metal processing
- Difficult-to-cut material sawing
- Continuous industrial sawing
FAQ
Q1: Where is your factory located?
A: Our factory is located in Nantong City, Jiangsu Province, China. It will takes about 1.5 hours from Shanghai Hongqiao station to our city.
Q2: What is your method of transaction?
A: We adopt the FOB(Free ON Board) transaction.
Q3: How about the payment term?
A: T/T 30% deposit, 70% of balance paid before shipment. (For other payment methods please contact our sales team)
Q4:What is the main advantage of M51 over M42 for this application?
A:The HD series uses M51 special high-speed steel to provide a higher-hardness, wear-resistant cutting edge for demanding materials that may be difficult for conventional M42 blades to handle.
Q5:What is the difference between HD and MD band saw blades?
A:The MD series focuses more on high cutting accuracy and smooth cutting surfaces, while the HD series focuses on higher tooth hardness, wear resistance and impact resistance for harder and more difficult-to-cut materials.
