MD Industrial Band Saw Blade Multi Tooth Pitch Selection For Efficient Metal Sawing
JSSCD MD Bi-Metal Band Saw Blade
Product Introduction
The JSSCD MD Bi-Metal Band Saw Blade is a high-performance metal cutting band saw blade designed for high cutting accuracy and smooth cutting surfaces.
The MD series uses a high-grade alloy steel strip from BÖHLER, Austria, as the backing material, with a molybdenum content of more than 2%, providing excellent toughness and fatigue resistance. The tooth tips are made of M42 high-speed steel, offering excellent wear resistance.
Through specialized heat treatment and precision processing technology, the MD series delivers longer service life, stable cutting performance and high cutting efficiency. It is suitable for both common steel materials and difficult-to-cut materials, including high-temperature alloy steel, die steel, bearing steel and stainless steel.
Key Features
High Cutting Accuracy
The MD series is designed for applications requiring high cutting accuracy and stable cutting performance.
Smooth Cutting Surface
Optimized tooth geometry and precision processing help achieve a smoother cut surface and reduce the need for additional finishing.
Premium BÖHLER B318 Backing Material
The blade body uses B318 high-grade alloy steel strip from BÖHLER, Austria, providing high toughness and fatigue resistance.
M42 High-Speed Steel Teeth
M42 high-speed steel tooth tips provide excellent wear resistance and are suitable for continuous industrial cutting applications.
High Toughness & Fatigue Resistance
The high-grade alloy backing material, combined with appropriate heat treatment, provides strong resistance to fatigue during continuous sawing.
Longer Service Life
The combination of M42 tooth material, high-quality backing steel and precision processing technology helps extend blade service life.
Suitable for Difficult-to-Cut Materials
The MD series can be used for a variety of common steels as well as difficult-to-cut materials such as high-temperature alloy steel, die steel, bearing steel and stainless steel.
Multiple Tooth Pitch Options
A wide range of tooth pitches is available to match different workpiece sizes and cutting requirements.
Available Sizes & Tooth Pitches
| Blade Size (Width * Thickness) |
Available Tooth Pitch / TPI |
| 19 * 0.90 mm |
10/14, 8/12, 6/10, 5/8, 4/6, 3/4 |
| 27 * 0.90 mm |
10/14, 8/12, 6/10, 5/8, 4/6, 3/4, 2/3 |
| 34 * 1.10 mm |
10/14, 8/12, 6/10, 5/8, 4/6, 3/4, 2/3, 1.4/2 |
| 41 * 1.30 mm |
5/8, 4/6, 3/4, 2/3, 1.4/2 |
| 54 * 1.60 mm |
3/4, 2/3, 1.4/2, 1/1.5, 0.75/1.25 |
| 67 * 1.60 mm |
3/4, 2/3, 1.4/2, 1/1.5, 0.75/1.25 |
| 80 * 1.60 mm |
3/4, 2/3, 1.4/2, 1/1.5, 0.75/1.25 |
Application
The JSSCD MD Bi-Metal Band Saw Blade is suitable for a wide range of metal cutting applications where cutting accuracy, surface quality and blade durability are important.
Suitable Materials
- Structural and common steel
- Medium and low-carbon steel
- Alloy steel
- High-temperature alloy steel
- Die steel
- Bearing steel
- Stainless steel
- Other difficult-to-cut steel materials
Recommended Applications
The MD series is suitable for:
- General metal processing
- Steel fabrication
- Steel service centers
- Machinery manufacturing
- Industrial metal cutting
- Precision metal cutting
- Continuous production sawing
- Cutting applications requiring a smooth cut surface
FAQ
Q1: What is your factory acceptance test method?
A: You can send us sample material to be cut, and we will perform a test cut using our machine. After the test is complete, we will provide you with detailed cutting data. (We will also send you a video of the machine cutting operation for your confirmation.)
Q2: How about your delivery time?
A: Generally, it will take 7-60 work days after receiving your order. The specific delivery time depends on the items and the quantity of your order.
Q3: Does the band saw blade have any international certifications?
A: Yes, we have obtained CE, ISO international
Q4: What is the backing material of the MD blade?
A: The MD blade uses B318 high-grade alloy steel strip from BÖHLER, Austria, as the backing material. The material contains more than 2% molybdenum and provides high toughness and fatigue resistance.
Q5: Can the MD blade cut high-temperature alloy steel?
A: Yes. The MD series is designed for both common steels and difficult-to-cut materials, including high-temperature alloy steel.
