LD Bimetallic Band Saw Blade Suitable For Diverse Material Sawing Needs
JSSCD LD Bi-Metal Band Saw Blade
Product Introduction
LD Bi-Metal Band Saw Blade for General Metal Cutting
The JSSCD LD Bi-Metal Band Saw Blade is a cost-effective and high-performance sawing solution designed for a wide range of conventional metal cutting applications.
The LD series combines an X32 backing material with Japanese-imported M42 high-speed steel tooth material. Combined with an optimized heat treatment process, the blade is designed to achieve excellent tooth wear resistance and high tooth-tip hardness.
With a strong balance between cutting efficiency, blade durability and cost-effectiveness, the LD series is suitable for continuous sawing and large-scale production applications.
It can be widely used for cutting common steel materials, including structural steel, medium- and low-carbon steel, alloy steel, alloy tool steel, tool steel and mold steel.
Key Features
1. High Cost Performance
The LD series is designed to provide a strong balance between blade performance and operating cost, making it suitable for customers who require reliable cutting performance for large-scale production.
2. M42 High-Speed Steel Teeth
The tooth material uses Japanese-imported M42 high-speed steel, providing a hard and wear-resistant cutting edge for conventional metal sawing applications.
3. X32 Backing Material
The blade uses X32 as the backing material, providing the foundation for the blade's overall strength and flexibility during continuous sawing.
4. Optimized Heat Treatment
An optimized heat treatment process is applied to the blade to improve the wear resistance and hardness of the tooth tip, helping maintain cutting performance during continuous operation.
5. Strong Continuous Sawing Capability
The LD series is designed for continuous sawing operations and is suitable for large-scale production environments where consistent blade performance is important.
6. Wide Material Compatibility
The LD blade can be used for a broad range of common steel materials, including structural steel, medium- and low-carbon steel, alloy steel, alloy tool steel, tool steel and mold steel.
7. Multiple Tooth Pitch Options
A wide selection of tooth pitches is available, allowing the blade to be matched to different workpiece sizes and cutting requirements.
Available Blade Sizes & Tooth Pitches
| Width * Thickness |
Available Pitch / TPI |
| 13 * 0.65 mm |
24T, 18T, 14/18, 14, 10/14, 8/12, 6/10, 5/8 |
| 19 * 0.90 mm |
10/14, 8/12, 6/10, 5/8, 4/6, 3/4 |
| 27 * 0.90 mm |
10/14, 8/12, 6/10, 5/8, 4/6, 3/4, 2/3 |
| 34 * 1.10 mm |
10/14, 8/12, 6/10, 5/8, 4/6, 3/4, 2/3, 1.4/2 |
| 41 * 1.30 mm |
5/8, 4/6, 3/4, 2/3, 1.4/2 |
| 54 * 1.60 mm |
3/4, 2/3, 1.4/2, 1/1.5, 0.75/1.25 |
| 67 * 1.60 mm |
3/4, 2/3, 1.4/2, 1/1.5, 0.75/1.25 |
| 80 * 1.60 mm |
3/4, 2/3, 1.4/2, 1/1.5, 0.75/1.25 |
Application
1. Structural Steel
The LD series is suitable for cutting structural steel in general metal fabrication and steel processing applications.
2. Medium- and Low-Carbon Steel
The blade is suitable for sawing medium- and low-carbon steel, making it a practical choice for general-purpose metal cutting.
3. Alloy Steel
The LD series can also be used for alloy steel cutting applications.
4. Alloy Tool Steel
For applications involving alloy tool steel, the M42 tooth material and optimized heat treatment provide a suitable cutting solution.
5. Tool Steel
The LD series is also applicable to tool steel sawing.
6. Mold Steel
The product information also lists mold steel among the applicable materials.
Recommended Application Areas
The LD series is particularly suitable for:
- Steel service centers
- General metal fabrication
- Steel processing
- Machinery manufacturing
- Industrial metal cutting
- Large-volume sawing operations
- Continuous production lines
FAQ
Q1: How about your delivery time?
A: Generally, it will take 7-60 work days after receiving your order. The specific delivery time depends on the items and the quantity of your order.
Q2: Are you a manufacturer or a trading company?
A: We are a professional manufacturer of saw blade grinders. We have a 30,000 square meter factory and a team of dedicated technicians specializing in design, manufacturing, and sales.
Q3: Does the band saw blade have any international certifications?
A: Yes, we have obtained CE, ISO international
Q4: What is the backing material of the LD blade?
A: The LD series uses X32 as the backing material.
Q5: Is the LD blade suitable for continuous cutting?
A: Yes. The LD series is specifically described as having strong continuous sawing ability and is suitable for large-scale production requirements.
