Complete Winter Maintenance Guide for Circular Saws in Russia
With years of in-depth experience in the Russian market, SAKOSIDE has specially developed a complete circular saw maintenance system for frigid climates, ensuring that your equipment maintains excellent performance even in the harshest winter conditions.
Pre-Winter Preparation Work
Comprehensive Inspection and Evaluation (Recommended to Be Completed Before Temperature Drops to -10°C)
- Electrical system insulation testing
- Hydraulic system tightness inspection
- Inspect and reinforce equipment sealing strips
- Verify the adequacy of workshop thermal insulation measures
- Prepare equipment insulation covers (for use during non-operating hours)
Key System Winter Maintenance Key Points
Hydraulic System Special Protection
- Replace with low-temperature hydraulic oil
- Maintain oil temperature within the operating range of 15-60°C
- Preheat for at least 15 minutes before daily startup
Pipeline and Sealing
- Inspect the tightness of all pipeline connection points
- Replace aging sealing components
- Ensure the hydraulic oil tank breather is unobstructed
Lubrication System Winter Configuration
Special Lubrication Scheme
- Bearing lubrication: Use low-temperature lubricating grease
- Guide rail lubrication: Apply low-temperature guide rail oil and increase lubrication frequency
- Gearbox: Replace with synthetic low-temperature gear oil
Electrical System Cold Protection Measures
- Activate heaters to maintain the operating temperature of PLC and drivers
- Regularly check the functional status of heating elements
- Control the humidity inside the control cabinet (recommended ≤ 60%)
- Inspect the flexibility of cable insulation layers
- Anti-freezing and anti-cracking protection for mobile cables
Special Daily Operation Procedures
Pre-Startup Checklist
Environmental Inspection
- No snow or ice around the equipment
- Workshop temperature not lower than the minimum allowable temperature of the equipment
- Thoroughly drain the air compressor
Preheating Procedure
- Electrical system preheating: 20-30 minutes
- Hydraulic system idle cycle: 10-15 minutes
- Low-speed operation of mechanical components: 5 minutes
Operational Notes
Cutting Parameter Adjustment
- Reduce the initial feed rate (recommended to 70% of the standard speed)
- Extend the saw blade running-in time
- Monitor changes in motor load
Continuous Monitoring Focus
- Temperature readings of each system
- Abnormal noise or vibration
- Changes in cutting quality
Shutdown Maintenance Procedures
Daily Shutdown
- Thoroughly drain the condensed water from the compressed air system
- Clean snow and ice off the equipment
- Cover with the insulation cover
- Record the daily operation data
Long-Term Shutdown
- Drain the cooling system fluid
- Perform regular idle operation of the hydraulic system
- Regularly power on to maintain the status of electrical components
SAKOSIDE Exclusive Winter Solutions
Intelligent Temperature Control System
Our high-end models are equipped with:
- Automatic temperature monitoring and regulation
- Staged heating control
- Remote monitoring and early warning
Special Material Application
- Cold-resistant structural steel: Critical components adopt low-temperature tough steel
- Special sealing materials: Seals that maintain elasticity at -50°C
- Anti-freezing coating: Special protective treatment for exposed components
Emergency Handling Guide
Quick Fixes for Common Problems
Equipment Fails to Start
- Check power supply voltage stability
- Confirm whether the control cabinet temperature meets the standard
- Inspect the emergency stop circuit
Reduced Cutting Precision
- Check the guide rail lubrication status
- Evaluate the hydraulic system response speed
- Confirm the impact of material temperature
Saxder Russia Service Center provides:
- 24/7 technical consultation hotline
- Fast supply of winter-specific spare parts
Saxder's Commitment
We are not only an equipment supplier, but also your technical partner in frigid climates. Every Saxder circular saw sold to Russia has undergone factory low-temperature testing, targeted design enhancement, and comes with complete winter operation training.
Technical Specifications
| Model |
Unit |
JSSCD-70NC/P |
| Mainframe dimensions |
mm |
2250*1790*1760 |
| Bar & round pipe |
mm |
10-70 |
| Angle bar & square bar |
mm |
10-60 |
| Saw blade size |
mm |
φ285*2.0*φ32 |
| Pin holes and hole diameters |
mm |
4*φ11*63 φ32 |
| Spindle motor power |
KW |
7.5(4P) |
| Spindle speed |
rpm |
20-168 |
| Feed servo motor power |
KW |
1.5 |
| Material removal length at the front end |
mm |
10-99 |
| Single feeding length(repeatable) |
mm |
6-860 |
| Hydraulic drive motor power |
KW |
1.5(4P) |
| Rated pressure of the hydraulic system |
mpa |
5.5 |
| Hydraulic oil capacity |
L |
70 |
Streamlined Operation via Advanced Control
Central to the machine is its dedicated PRECISION CNC CONTROL PLATFORM. This advanced unit meticulously manages critical cutting parameters including velocity and angular orientation, guaranteeing efficient and accurate results for every workpiece. Operation is simplified through an intuitive Human-Machine Interface (HMI).
Frequently Asked Questions
Q1: Are you a manufacturer or a trading company?
We are a professional manufacturer of saw blade grinders. We have a 30,000 square meter factory and a team of dedicated technicians specializing in design, manufacturing, and sales.
Q2: Where is your factory located?
Our factory is located in Nantong City, Jiangsu Province, China. It will takes about 1.5 hours from Shanghai Hongqiao station to our city.
Q3: What is your factory acceptance test method?
You can send us sample material to be cut, and we will perform a test cut using our machine. After the test is complete, we will provide you with detailed cutting data. (We will also send you a video of the machine cutting operation for your confirmation.)
Q4: What is your method of transaction?
We adopt the FOB(Free ON Board) transaction.
Q5: How about your delivery time?
Generally, it will take 7-60 work days after receiving your order. The specific delivery time depends on the items and the quantity of your order.
Q6: How about the payment term?
T/T 30% deposit, 70% of balance paid before shipment. (For other payment methods please contact our sales team)
Q7: Does the band saw blade have any international certifications?
Yes, we have obtained CE, ISO international certification.
